Trace Memory Controller

The Trace Memory Controller (TMC) enables trace data to be passed to system memory and other high speed devices and links in the System-on-Chip as part of the debug system. Debug system designs include the following components:

Embedded Trace Buffer (ETB) enables trace data to be stored in a dedicated SRAM, used as a Circular Buffer.

Embedded Trace FIFO (ETF) enabled trace data to be stored used either as a Circular Buffer or as a FIFO.

Embedded Trace Router (ETR) enables trace data to be routed over an AXI bus to system memory or other AXI slaves.



Explore This Technology

Image of CoreSight Trace Memory Controller
